Application
KDX3-ID is mainly used for residual current protection under AC50/60Hz monopole 230v or two or four poles 400V voltage. When electric shock or leakage exceeds the specified current, the power supply can be automatically cut off immediately. It can effectively protect personal safety and avoid equipment damage. The circuit breaker also has the functions of overload, short circuit protection and infrequent line change. Products are suitable for industrial, commercial, building, residential and so on.
Main technical parameters
Type | KIDX3-63 RCCB |
Model | Electronic type / magnetic type |
Residual Current characteristics | A, AC |
Pole NO | 2P/4P |
Rated Current (A) | 10A,16A,20A,25A,32A,40A,63A |
Rated Voltage (V) | 240/ 415V |
Rated Residual operating current | 30 ma , 100ma ,300ma ,500ma |
Rated conditional resdual short circuit current | 6KA |
Electro-machanical endurance | over 4000 cycles |
